Strip Linear
Single Color Strip Light
How should Single Color Strip Light be specified for a commercial or architectural lighting project?
A single-color strip family for white or fixed-color linear lighting. The migrated 5050 example states DC12V/DC24V, 60 LEDs/m and 14.4 W/m; the exact chip, CCT, CRI, PCB, IP process and output must be confirmed per SKU.
- Power
- model-dependent; example variants 13 W/m rated
- Input
- DC12V / DC24V; exact variant to confirm
- Efficacy
- model-dependent; use exact datasheet
- CCT
- model-dependent white CCT or fixed color
- CRI
- CRI 80+ / CRI 90+ are listed for common white variants
- Protection
- IP20/IP54/IP65/IP67 routes listed; exact SKU/process to confirm
Final specifications, certificates, control compatibility, MOQ and delivery terms are confirmed against the selected configuration and destination market.
Decision summary
What buyers should know
- Select the exact variant by voltage, LED/color architecture, density, PCB width, cut length, output, IP process and installation system.
- Control and smart-system support is project-dependent and must be confirmed against the selected driver/controller/gateway.
- Use the current exact-model datasheet, sample and certificate coverage—not a series-level marketing statement—as final project evidence.
Buyer fit
Where this product fits—and where it does not
Use these boundaries before comparing detailed models. Project drawings and the selected SKU remain the final specification basis.
Best for
- Commercial cove and linear accent lighting single-color LED strip can be selected as part of a strip, profile, driver and control system.
- Project-specific OEM/ODM requirements Length, PCB, color, IP process, connector and packaging options can be reviewed during RFQ.
- Stable white or fixed-color lighting Avoids multi-channel color control where one consistent light color is required.
Confirm another option when
- Final specification without an approved exact-model datasheet Series-level information does not replace the confirmed SKU, test report or engineering drawing.
- Long runs without voltage-drop and thermal review Run length, cable, power supply, profile and operating temperature affect performance and reliability.
Technical selection
Specifications and available variants
Select the family or model first, then confirm drawings, photometric files, driver and market-specific compliance before order.
Electrical
- Input voltage
- DC12V / DC24V; exact variant to confirm
- Power range
- model-dependent; example variants 13 W/m rated
- Driver / control
- Can be configured for project-dependent dimming or smart control after compatibility review. Confirm the selected driver/controller, voltage, load, channel count, wiring, gateway, commissioning responsibility and destination market. Customer-specified overseas systems may be reviewed; support is not standard on every variant.
Optical
- Efficacy
- model-dependent; use exact datasheet
- Lumen output
- catalog examples vary by LED family and density
- CRI options
- CRI 80+ / CRI 90+ are listed for common white variants
- CCT options
- model-dependent white CCT or fixed color
- Beam angle
- Confirm for selected configuration
Mechanical
- Dimensions
- PCB width and cut length vary by variant; examples include 8 mm and 10 mm PCB
- Materials
- Flexible PCB with LED components; exact copper weight and process to confirm
- IP rating
- IP20/IP54/IP65/IP67 routes listed; exact SKU/process to confirm
- Mounting
- Adhesive mounting or aluminum profile/system installation
- Installation notes
- Confirm profile, diffuser, adhesive, heat dissipation, run length and waterproof termination.
Model and variant matrix
| Model / Variant | Power | Dimension | CCT | CRI | Efficacy | Lifespan |
|---|---|---|---|---|---|---|
| 5050-60-12V/24V-10MM | 14.4 W/m max; 13 W/m rated in 2025 catalogue | 10 mm PCB; 50 mm/3 LEDs at 12V or 100 mm/6 LEDs at 24V | 2200K-6500K white range in catalogue family | CRI 80+ / CRI 90+ available | 1250 lm/m at 2700K Ra80 or 1350 lm/m at 6000K Ra80 in catalogue | Confirm for selected configuration |
| 2835-60-12V/24V-8MM | 14.4 W/m max; 13 W/m rated in 2025 catalogue | 8 mm PCB; 50 mm/3 LEDs at 12V or 100 mm/6 LEDs at 24V | 2200K-7000K white range in catalogue family | CRI 80+ / CRI 90+ available | 1350 lm/m at 2700K Ra80 or 1630 lm/m at 6000K Ra80 in catalogue | Confirm for selected configuration |
Detailed specification reference
| Parameter | Value | Condition / Evidence |
|---|---|---|
| Family voltage | DC12V / DC24V | depends on variant catalog PDF pages 7-26 |
| LED families | 3528, 5050, 2835, 3014, 2216, 5730 and side-view families | series-level catalog contents and pages 7-26 |
| Color temperature | Fixed color or white; white ranges vary by LED family | confirm exact SKU catalog PDF pages 7-26 |
| Waterproof process | IP20 bare, IP54 glue, IP65 tube/extrusion, IP67 potting/solid extrusion, and neon extrusion routes are listed | process and size vary catalog PDF page 3 |
Smart and project integration
Control compatibility
Control support is configuration-dependent. Driver, protocol, gateway, wiring, voltage and certification market must be reviewed together.
Can be configured for project-dependent dimming or smart control after compatibility review. Confirm the selected driver/controller, voltage, load, channel count, wiring, gateway, commissioning responsibility and destination market. Customer-specified overseas systems may be reviewed; support is not standard on every variant.
Evidence and documents
Compliance, catalogues and specification evidence
Certificate applicability and document revision must match the ordered configuration and destination market.
Evidence notes
- Listed catalogue variants and values were transcribed from the 2025 Besenled LED strip and neon catalogue. catalogue
- Migrated WooCommerce wording is treated as a claim ledger and not as final test evidence where it lacks an exact-model source. methodology
B2B procurement
Prepare a quote-ready request
Besenled confirms commercial terms after the product configuration, quantity, project schedule and target market are defined.
- MOQ
- Project-dependent; confirm by exact variant, quantity and customization scope.
- Sample policy
- Sample can be quoted after voltage, color/CCT, PCB, IP process, driver/controller and accessory requirements are confirmed.
- Sample lead time
- Confirm for selected configuration
- International lead time
- Confirm for selected configuration
- Warranty
- Project- and model-dependent; confirm in the quotation and approved datasheet.
- Quote basis
- Rfq Required
Information needed for RFQ
- 1 Voltage, color/CCT, CRI and target outputNeeded to select the strip family and exact variant.
- 2 LED density, PCB width, cut length and run lengthNeeded for dimensions, power calculation, voltage drop and accessory matching.
- 3 IP process, profile and installation environmentNeeded for heat dissipation, sealing and mounting selection.
- 4 Driver, controller and smart-system requirementNeeded to review dimming, channel, gateway, wiring and protocol compatibility.
- 5 Quantity, destination market, documents and target dateNeeded to confirm MOQ, sample, compliance scope, packaging and lead time.
Buyer questions
FAQ and source notes
- Last fact checked
- August 5, 2026
How should Single Color Strip Light be specified?
Start with application, voltage, color/CCT, LED density, output, PCB width, cut length, IP process, profile, driver/controller and destination-market requirements. Then confirm the exact model and sample.
Are all control protocols supported as standard?
No. DALI/DALI-2, 0-10V, Zigbee, Bluetooth Mesh, DMX512, phase-cut, Tuya, Casambi, KNX/BMS or a customer-specified ecosystem require a compatible driver/controller/gateway and project review.
What evidence should be approved before ordering?
Approve the exact-model datasheet, dimensions, electrical load, sample, applicable certificate coverage, control compatibility and packaging requirement.
Next procurement step
Request a configuration review and quotation
Send the application, model or required performance, quantity, voltage, controls, destination market and target schedule.
